Diode LED SWITCHEX DI-24V-SE-60W 60W LED Driver — 24VDC DC
The Diode LED SWITCHEX DI-24V-SE-60W LED Driver and dimmer switch is an innovative all-in-one solution that merges a 60W power supply with a reliable wall dimmer. This 24VDC Constant Voltage driver eliminates compatibility issues between separate components by fitting directly into a standard electrical gang box. It is an ideal choice for simplifying low-voltage LED installations, offering a Class 2 safety rating and power failure memory that returns to the previous setting once power is restored.
Key Features
- Power Output: Delivers a maximum load of 60W at 2.5A for 24VDC lighting systems.
- Input Voltage: Accepts a standard 120VAC input with a range of 108-132VAC.
- Output Voltage: Provides a stable 24VDC output for compatible LED products.
- Dimming Range: Features a superior 100% to 5% smooth, flicker-free dimming range.
- Minimum Load: Engineered with no minimum load requirement for maximum application flexibility.
- Dimensions: Compact housing measuring approximately 4.1 in. L x 2.1 in. W x 1.4 in. H.
- Enclosure Type: Integrated wall switch design that fits into a single-gang electrical box.
- Class 2 Status: UL Listed Class 2 power supply ensures safe and compliant low-voltage operation.
- Efficiency: High-performance design with an efficiency/power factor of 0.69.
- Certifications: UL Listed for US and Canada and FCC approved for Class B digital devices.
Physical Design & Installation
The SWITCHEX unit is specifically designed for installation in standard recessed electrical wall boxes. It comes with three interchangeable faceplates (Glossy White, Light Almond, and Brown) to match various interior decors. The included voltage barrier partition allows for the safe installation of high and low voltage circuit conductors within the same switch box, streamlining the labor for professional contractors.
Dimming & Controls
This integrated unit provides architectural-grade 100%-5% dimming for constant voltage LED fixtures. The sliding dimmer lever allows for intuitive manual control, while the preset on/off switch maintains the desired light level. An adjustable voltage output dial is also located on the unit to help mitigate voltage drop across longer wire runs.
Performance & Build
The DI-24V-SE-60W is engineered for reliability with a standby power consumption of ?0.5W and protection against common electrical faults. It is rated for indoor and damp locations (IP20), making it suitable for kitchens and bathrooms. The unit is backed by a 5-year warranty, ensuring long-term performance in residential and commercial projects.
Typical Applications
- Residential under-cabinet LED tape lighting in kitchens.
- Accent and cove lighting in dry or damp-rated indoor environments.
- Commercial retail display lighting requiring localized, integrated dimming control.
