Description
Premium architectural-grade LED tape lighting from GM Lighting’s LTR-S Specification Series. The ultimate linear lighting solution for applications that demand the best optics in the industry, featuring truly state-of-the-art features that define the Spec Series as the gold standard for architectural-grade LED tape.
Series Overview
The LTR-S Specification Series is available in two power outputs (2.5W/ft and 5.8W/ft), four color temperatures (2700K, 3000K, 3500K, 4000K), and two reel lengths (16′-4″ and 98′-6″), providing unmatched flexibility for any project requirement. Each configuration delivers exceptional 95+ CRI color rendering with industry-leading optical performance.
Key Features
- 280 LEDs per meter (72 LEDs/ft) for smooth, uniform illumination with no visible hotspots
- 95+ CRI for accurate color rendering in residential and commercial spaces
- 120° viewing angle provides wide, even light distribution
- Dimmable for complete lighting control and ambiance customization
- Cuttable every 1″ for precise field customization
- 10mm PCB width fits into tight mounting channels and profiles
- 3M adhesive back for secure, easy installation
- Premium diodes ensure long-lasting, reliable performance
- Remote control compatible with GM’s LUXcontrol™ App and controllers
- Closet Rated – compliant with NFPA 70, NEC section 410.16 (A)(3) and 410.16 (C)(5)
- UL listed, Class 2, Title 24 compliant when used with specific drivers
- 5-year warranty when paired with GM power supply
Technical Specifications
2.5W/ft Models:
- Power: 2.5 watts per foot
- Lumens: 216-261 lumens per foot (varies by CCT)
- Maximum Run: 32′-8″ on a given lead
- 16′-4″ Reel: Includes 3 ESTW-60 Sure-Tite connectors
- 98′-6″ Reel: Includes 10 ESTW-60 Sure-Tite connectors
5.8W/ft Models:
- Power: 5.8 watts per foot
- Lumens: 504-520 lumens per foot (varies by CCT)
- Maximum Run: 16′-4″ on a given lead
- 16′-4″ Reel: Includes 3 ESTW-60 Sure-Tite connectors
- 98′-6″ Reel: Includes 10 ESTW-60 Sure-Tite connectors
Universal Specifications:
- Voltage: 24V DC
- Color Temperatures: 2700K (warm white), 3000K (soft white), 3500K (neutral white), 4000K (cool white)
- CRI: 95+
- Operating Temperature: -4°F to 122°F
- PCB Width: 10mm
- LED Density: 280 LEDs/meter, 72 LEDs/foot
- Viewing Angle: 120°
Applications
Ideal for under cabinet lighting, cove lighting, accent lighting, architectural details, display cases, closets, shelving, and any application requiring premium optics, high CRI, and professional-grade linear LED illumination. The range of color temperatures and power outputs ensures the perfect solution for residential, hospitality, retail, and commercial environments.
Note: For proper thermal management, use mounting channel to mount the 5.8W product. Custom options available – consult factory.
