LEDVANCE SYLVANIA 62448 LED Jelly Jar Vapor Tight — Dual Selectable
The LEDVANCE SYLVANIA 62448 is a dual selectable LED jelly jar vapor tight fixture delivering 1000 / 2000 lumens with field-selectable 10W / 20W wattage and selectable 3000K / 4000K / 5000K color temperature. It operates on 120-347V with standard 0-10V dimming. Rated IP65 for wet location use, this fixture is designed for commercial and industrial applications requiring sealed and durable illumination.
Key Features
- Selectable Wattage: 10W / 20W
- Selectable CCT: 3000K / 4000K / 5000K
- Delivered Lumens: 1000 / 2000 lm (at 4000K)
- Distribution: Type V
- Voltage: 120-347V
- Dimming: 0-10V dimmable
- CRI: >80
- Efficacy: 100 LPW
- Bug Rating: B1U3G1
- Environmental Rating: IP65, Wet Location
- Certifications: cULus to UL1598, RoHS, FCC
- Rated Life: 50,000 hours (L70)
- Operating Temperature: -40°F to +122°F (-40°C to +50°C)
- Warranty: 5-Year Limited Warranty, NLB Trusted Warranty Program
Typical Applications
- Utility corridors
- Stairwells
- Storage rooms
- Parking garages
- Mechanical rooms
Performance & Light Output
Selectable wattage allows adjustment between 15W, 20W, and 25W to match lighting requirements. CRI >80 for general commercial illumination. Designed for consistent output in wet and harsh environments.
Electrical & Controls
Operates on 120-347Vac with power factor greater than 0.9 and THD below 20%. Compatible with standard 0-10V dimming control systems.
Construction & Durability
Sealed construction rated IP65 for wet location use. Designed for reliable performance in moisture-prone environments.
Installation & Mounting
Supports wall mount, ceiling mount, or pendant mount installation. ½” conduit by others. Factory default configuration is set to 20W and 4000K.
Included
- Fixture housing and lens assembly
