Description
RAB ND22-50 8 in. Round Downlight — 50W / Selectable CCT
The RAB ND22-50 is a versatile 8-inch round downlight delivering up to 4708 lumens using 50W. This modular commercial downlight features field-adjustable wattage and CCT, making it ideal for various lighting applications. With a selectable CCT range of 2700K to 5000K, it offers flexibility in achieving the desired ambiance.
Key Features
- Wattage Options: 50/40/30W selectable
- Lumens Output: 4500/3800/2900lm
- Efficacy: 90/95/96.7 lm/W
- Voltage: 120-277V
- Dimming: TRIAC/ELV and 0-10V compatible
- Beam Angle: Adjustable 30° to 50°
- CRI: 90 for excellent color rendering
- Lifespan: 50,000 hours
- Certifications: ENERGY STAR, Title 24 JA8, RoHS, TAA compliant
- Environment: Suitable for wet locations
Construction & Aesthetics
This downlight features a curved decorative diffuser and is compatible with various trims and accessories. It is designed for both retrofit and new construction applications, accommodating up to 2” ceiling thickness.
Electrical & Installation
The ND22-50 operates on a 120-277V system and supports dimming down to 10%. It includes a constant current driver and is compatible with emergency backup options.
Light Output & Performance
With a high CRI of 90 and adjustable beam angles, this downlight ensures superior light quality and performance. It maintains color stability with less than 200K shift over five years.
Typical Applications
- Commercial spaces
- Retail environments
- Hospitality settings
- Outdoor canopies
- Wet locations
